| Machine material |
All aluminum sandblasting oxidation |
| Laser |
Service life more than 20000–30000 hours |
| Laser wavelength |
10600nm |
| Output power |
30W (KC130), 40W (KC140), 60W (KC160) |
| Marking speed |
≤20000mm/s |
| Controller |
10.2 inch touch controller |
| Cooling system |
Air cooling |
| Focus lens |
160mm |
| Minimum linewidth |
0.03mm |
| Repetition accuracy |
0.01mm |
| Marking range |
110mm × 110mm (optional) |
| Positioning mode |
Red light indication |
| Number of rows |
Any line within the marking range |
| Production line speed |
0–280m (depending on material) |
| Multilingual |
English, Spanish, German, Chinese, Russian, Arabic, etc |
| Jurisdiction |
Multi-user management authority |
| Operating system |
Linux system |
| Inkjet mode |
Static, analog, encoder |
| Reserved signal |
Start, print status, finish, fault |
| Data protection |
With power-failure data protection energy |
| Monitor |
Overspeed alarm function |
| De crossing |
Automatic removal of intersections |
| Coding software |
Single and double machine code sending |
| Typeface |
Chinese & English, numbers, traditional, etc |
| File format |
BMP, DXF, HPGL, JPEG, PLT |
| Bar code |
CODE39, CODE128, CODE126, QR |
| Power supply |
AC 220V / 50Hz |
| Power consumption |
800W (30W/40W), 1500W (60W) |
| Net weight |
32KG (30W/40W), 38KG (60W) |
| Overall dimension – Nose |
692mm × 200mm × 158mm |
| Overall dimension – Control box |
403mm × 320mm × 157mm |
| Environment requirement |
Temp 0–45°C; Humidity ≤95% |
